| Model | ZMTEC | ||
| Input Power Supply | 230V AC, ±10 % @ 50Hz. | ||
| Operating Mode | 1. Event Mode | 2. Time Mode | 3. Oscilloscope Mode |
| Time Range | 0.1ms to 99 Hrs | ||
| Accuracy of Time | 0.05% | ||
| Resolution of time | 0.1ms | ||
| Event Range | 0 to 9999 | ||
| Oscilloscope Range | 500.0 µs to 50.00 s | ||
| Programming | By key pad | ||
| Display | 20X4 LCD | ||
| Operating Temperature | 10oC to 45oC | ||
| Storage Temperature | 5oC to 55oC | ||
| Dimension | 200mm(W) X 200mm(D) X 200mm(H) | ||
| Weight | 3kg. (Approx.) | ||
Note : We Can Upgrade Products With Time To Give Improved Quality
