| Model |
ZM5KHRJ |
| Fixed Resistor |
5 MΩ, 10 MΩ, 100 MΩ, 200 MΩ, 500 MΩ, 1 GΩ, 10 GΩ, 100 GΩ, 500 GΩ,1000 GΩ. |
| Maximum Test Voltage |
5000V DC |
| Accuracy |
2% for 5 MΩ, 10 MΩ, 100 MΩ, 200 MΩ, 500 MΩ, 1 GΩ, 10 GΩ. |
| 5% for 100 GΩ, 500 GΩ,1000 GΩ. |
| Dimension |
400mm(W) X 140mm(D) X 300mm (H) |
| Weight |
0.6kg. (Approx.) |
